HP Color LaserJet Pro MFP M479fdw
Microsoft Windows 10 (64-bit)

what is the biggest 2242 that the HP 200-010 pc can handle? i have installed a kingspec 1TB but it will not recognize it!

6 REPLIES 6
HP Recommended

Hi @JKaKarot27



There is no limit but if you put a NVMe disk it must be SATA-3 (it has two connectors).



- if I can help solve your question or issue, please click on ACCEPT AS SOLUTION or click the YES button if my answer was helpful.
HP Recommended

This is what I put in there

KingSpec 1TB M.2 2242 PCIe 4.0 SSD - Read Speed up to 7400MB/s, NVMe Internal SSD 3D Gen4 NAND Flash, M2 for Laptop Desktop



And it will not recognize it because I think it's too big I think these PCS can only handle

HP Recommended

As indicated it is not the size but that you put an NVMe disk you should put M.2 SATA disks.dual connector




- if I can help solve your question or issue, please click on ACCEPT AS SOLUTION or click the YES button if my answer was helpful.
HP Recommended

Ahhhhh i see, thank since I did not see the other notch in there on the board itself I thought this would work thank you for the info

HP Recommended

From what I'm seeing it looks like anything above 256 is only a single notch

HP Recommended

You´re welcome, but I tell you this 'so you understand, but the reason is that it has no processor or chipset that can support M.2 NVME disks even if they both use the same slot, with the SATa-3 there is a pin in the air but the same M.2 slot is used.

I hope this solved your query.

- if I can help solve your question or issue, please click on ACCEPT AS SOLUTION or click the YES button if my answer was helpful.
