7605 smart tank address labels question

[Daves73]

Just got a 7605  was going to print on to C4 envelopes but they don't fit unfortunately.  Does anyone know if the 7605 can print address labels?  I'm not thinking thr single rolls but the a4 page of labels that should fit in the paoer tray but if I put one in I suspect it won't recog ise paper being in the tray.

Any help gratefully received!!

[Dragon-Fur]

@Daves73

Welcome to the HP English Community --

Yes, the printer should print labels.

Enough different kinds of paper are supported that the task should be workable.

The trick is to not overdo the type of label paper.

Better:  Sheet of standard white matte labels - Avery (for example)

Not-so-much (Avoid):  Clear, colored, or shiny (very glossy) labels, slick backside of paper, and anything that says "Stickers" on the package.

===============================

Load Paper

Load five to eight sheets of paper in the in-take tray.

Top toward the back, print side down.

Unsure about how the labels will print or how they will look?

Test

Mark a piece of plain paper with a X - load the paper into the tray (with other plain paper) as if it is the label paper.

Run the print job - print one sheet of labels on the plain paper.

Check the results.

 User Guide - HP Smart Tank 7600 series

Starting on Page 17

===============================

Printer - Tray and Paper

EWS > HP Document / How-to (Original Format)

Use the HP printer Embedded Web Server (EWS)

NOTE:  Find printer IP address

Section Open the EWS over a local network orientation

Open your Browser > Type / enter the Printer IP address into URL / Address bar

EWS – Tray and Paper Management

Standard EWS

Open your Browser > Type / enter the Printer IP address into URL / Address bar

Tab Settings > Preferences > Tray and Paper (Management)

Select / Adjust settings for Paper Size / Type

Model and EWS version Dependent:  Advanced section

Click Apply to save changes

If, when you check EWS for Tray and Paper Type, you find a "Thick" paper or "Brochure (matte)" type, try one of those.

EWS_9025_Preferences_Tray_and_Paper_Management_All_11

===============================

Job Configuration

Windows - Full Feature Software / full driver printer software installed

Example - Exported to PDF - Adobe Reader - Label Print (full size sheets)

Avery_L7160_Sample_Label_1

===============================

Message Content References

Product Specifications for the HP Smart Tank 7605 All-in-One (28C02A)

Paper handling

Input capacity	Up to 250 sheets
Standard input capacity (cards)	Up to 30 cards
Output capacity	Up to 100 sheets
Media sizes supported (metric)	A4; A5; A6; B5 (JIS); Envelope (DL, C5, C6, Chou #3, Chou #4); Card (Hagaki, O**bleep**u Hagaki)
Media sizes supported (U.S. standard)	Letter; Legal; Government Legal; Executive; Statement; 4 x 6 in; 5 x 7 in; 8 x 10 in; L; Photo 2L; Envelope( #10, Monarch, 5.5 bar); Card (4 x 6 in, 5 x 8 in)
Media sizes, custom (metric)	88.9 x 127 mm to 215.9 x 355.6 mm
Media sizes, custom (U.S. standard)	3.5 x 5 in to 8.5 x 14 in
Media types	Plain Paper, HP Photo Papers, HP Matte Brochure or Professional Paper, HP Matte Presentation Paper, HP Glossy Brochure or Professional Paper, Other Photo Inkjet Papers, Other Matte Inkjet Papers, Other Glossy Inkjet Papers, Light/Recycled
Media weight supported (metric)	Plain paper: 60 to 105 g/m²; Envelopes: 75 to 90 g/m²; Cards: up to 200 g/m²; Photo paper: up to 250 g/m²
Media weight supported (U.S. standard)	16 to 28 lb
Borderless printing	Yes (up to 8.5 x 11 in, 210 x 297 mm)

=--=--=--=--=--=--=--=--=--=--=--=--=--=--=--=--=--=

References / Resources

HP Printer Home Page - References and Resources

Learn about your Printer - Solve Problems

“Things that are your printer”

When the website support page opens, Select (as available) a Category > Topic > Subtopic

NOTE: Content depends on device type and Operating System

Categories: Warranty Check, Alerts, Troubleshooting, Ink & Paper, HP Software & Drivers / Firmware Updates, Setup & User Guides, Product Specifications, Account & Registration, Warranty & Repair

Open

 Product Home - Printers

 Enter the device type and model name of your HP product

OR

 Select a saved product from HP Account Dashboard

OR

HP Smart Tank 7605 All-in-One
