Acquired Z400 & xw8400 - which 1 to upgrade + issues

[Biomecanoid]

I have the 003 heatsink  will that do for the x5365 ? i have also found 001 heatsinks on ebay.

Thank you, Merry Christmas

[SDH]

You're going from a single 5130 at max TDP of 65W to two X5365 with running at max TDP of 150W each.  The -002 is what HP settled on for their later hotter workstations.  They settled on the -003 for your cold slow workstation.  You tell me, what one do you want to run two of?  The -001 is equal to the -002 if you have a fan that runs on that old thing.

You even can look into the double tall double fans heatsink/fans for each processor.  It was developed for the xw8600, however.  You can experiment like others have.  Your yield:  Passmark score from what you have is 1366, and what you'll go to is 6207.  What can that Z400 do with one X5690?   8782

[Biomecanoid]

Hi,

So from what i understand we need 4 heatpipes to cool the 150watt cpu. So will that do ?

https://www.ebay.co.uk/itm/HP-WorkStation-XW8600-XW6600-CPUs-Heatsink-with-Fan-446358-001/3619890081...

Thanks

[Biomecanoid]

UPDATE Z400:

CPU:  x5690

PSU:   475 watt

Ram: 32gb

GPU: Nvidia 1060 3gb

SSD: RAID0 2x Crucial_CT250MX2

HDD: RAID0 2x 1tb Hitachi drives

FAN: Extra 80mm high airflow fan ( from a server ) at the front
