Guidelines
We have new content about Hotkey issue, Click here to check it out!
Common problems for Battery
We would like to share some of the most frequently asked questions about: Battery Reports, Hold a charge, Test and Calibrating Battery . Check out this link: Is your notebook plugged in and not charging?
Locked

‎07-21-2019 03:21 PM

HP Recommended
Product: hp15-db0004dx
Operating System: Unknown

 hp15-db0004dx  ryzen 3   i want to upgrade the storage to the latest tech. is my laptop compatible with nvme?

1 person had the same question
3 REPLIES 3

‎07-21-2019 03:31 PM

HP Recommended

@PapaRyzen



Your machine has  1 TB 5400 rpm SATA now. You can add M.2 SATA SSD to your machine using Crucial MX500 or Samsung 860 series to your machine. For example



      https://www.crucial.com/usa/en/hp-15-db0004dx/CT14359420



You would need following parts before you can add M.2 SSD.



  • Solid-state drive bracket part # L20458-001
  • Solid-state drive connector board part # L22542-001
  • Solid-state drive cable part # L20456-001

Regards.

BH
***
**Click the KUDOS thumb up on the left to say 'Thanks'**
Make it easier for other people to find solutions by marking a Reply 'Accept as Solution' if it solves your problem.




Was this reply helpful? Yes No

‎07-21-2019 03:41 PM

HP Recommended

thank you.  im still have questions.  there is  m.2 of different shape  a square one and a rectangler narrow shap m.2 ssd.    which one works for my laptop.   also which one on this amazon list can you  recommend        samsungAmazon product

Was this reply helpful? Yes No

‎07-22-2019 04:55 AM

HP Recommended

Hi,

You do not need any extra parts to install an M2 SSD in the notebook. It supports M2 SATA3 and much faster M2 PCIe NVMe SSD.

Examples:

https://www.amazon.com/Samsung-970-EVO-1TB-MZ-V7E1T0BW/dp/B07BN217QG/ref=sr_1_1?keywords=970+evo&qid...

https://www.amazon.com/Samsung-860-SATA-Internal-MZ-N6E1T0BW/dp/B07822Z77M/ref=sr_1_2?keywords=860+e...

On page 47 of service manual you can see the steps to install the drive

http://h10032.www1.hp.com/ctg/Manual/c06245081



you will need to reinstall the OS on the SSD for performance gain.



Hope it helps,

David

Was this reply helpful? Yes No
