HP DeskJet GT 5820 printing incomplete pictures - help appreciated!

[Cher-1003]

Hi everyone!

I am currently having a printing problem with my printer, an HP DeskJet GT 5820, which I haven't encountered before. It seems that I am unable to print complete pictures. That is, the printer cuts off the image (i.e. stops printing) at a certain point and then ejects the entire sheet, without an error message or pop-up showing on my screen. I am not sure whether it is the document format or the type of paper that has gone wrong, but this printing error does not happen when I print a text-only document.

I am attaching a couple of photos for reference:

These pictures that I am trying to print are images formatted on a Microsoft Word document and these were printed using that program. This is also what I have been doing ever since, but I think that this is the first time that I had this concern. I have already tried Google-searching about this one, but to no avail.

Help in the form of advice and/or suggestions will be much appreciated! Thank you!

[Jeet_singh]

@Cher-1003,

Thank you for posting this on HP Support Forums!

I see from your post that you're having issues while printing from your HP DeskJet printer. Don't worry we'll work together to help you find a solution.

To provide you with an accurate solution, I'll need a few more details:

Are you having issues while making a copy from the printer?

Have you tried to run the HP Print and Scan Doctor.

Did you try to uninstall and reinstall the printer drivers:

Perform a Hard reset on the printer and make sure that the printer is connected directly to the wall outlet and not to the surge protector.

With the printer turned on, disconnect the power cord from the rear of the printer and also unplug the power cord from the wall outlet.

Remove USB cable, if present.

Wait for 2-3 minutes, press and hold the power button on your printer for about 30 seconds to remove any additional charge.

Now plug back the power cable straight to a wall outlet without any surge protector or an extension cord and then plug back the power cord to the printer.

Turn on the printer and wait till warm-up period finishes and the printer is idle.

If you are facing any issue while using the printer then try using HP Print and Scan Doctor (PSDR). PSDR is an automated tool which can diagnose and resolve printing and scanning problems. Please go to this link: HP Printers - Using HP Print and Scan Doctor (Windows)  to download and run HP PSDR. Once you open the program, select your printer and click on “Fix Printing” to automatically diagnose and fix the issue.

Let’s try and make a “photocopy” to determine whether the issue is with the printer or not. Place a document on the scanner glass and choose “Copy” option. If the printer is making a good copy, then the printer hardware is fine.

If the copy comes out fine, then I would suggest this could be to due to software or driver conflict.

I suggest you uninstall the printer drivers from the root level and then reinstall them by following the below steps:

• Press “Windows key” + “r” to get the “Run” window.
• Type "services.msc" to get Services – Go to “Print spooler” – Right-click and “Stop” the service.
• Now again open "Run" - Type “spool” and ok - Go to PRINTERS folder - delete everything in that folder.
• Go to services again - Start the print spooler.
• Now check for issue resolution.
• If the issue persists, also try clean installing the printer drivers. Here are the steps:
• First, unplug the USB cable from the printer if present.
• Go to Control panel – Programs and feature – Select all the HP DeskJet printer entries and uninstall them.
• Now go to Control panel – Devices and printer – Select all the printer entries and remove the device.
• Press the "windows key" + "r" to get the "Run" window open - Type "printui.exe /s" (There is a space between .exe & /) and press enter.
• Under print server properties, go to drivers - remove any entry there as well.
• Again, go to the Run window, type – “c:/programdata” – Go to Hewlett Packard folder, remove any printer related folders & files.
• Restart your computer.
• Please click here to download and install the software.
• Connect the USB cable if prompted and follow the on-screen instructions to complete the installation.

Please let me know if this resolves the issue, or if you require further assistance!

Eagerly waiting for your response!

that said, If the information I've provided was helpful,

give us some reinforcement by clicking the solution and kudos buttons,

that'll help us and others see that we've got the answers!

Good Luck.
